BSA PCP ELECTRIC COMPRESSOR

BSA PCP ELECTRIC COMPRESSOR

Regular price £400.00 GBP
Regular price Sale price £400.00 GBP
Sale Sold out
Taxes included.

PCP ELECTRIC COMPRESSOR
The BSA electric compressor comes with a 240 v power lead and plug allowing it to be used from a domestic socket or alternatively it has jump lead style crocodile grips to connect it to a standard car battery. All you need to do is plug it into your PCP and power it on. It also has a gauge that can be set to the desired fill volume and it will automatically turn itself off preventing over filling. A spares kit is also provided in the box. Our standard filler probes can be used via a quick fill.

  • Dual power supply: Operates on AC (220V / 110V) or DC (12V), controlled via a change-over switch
  • High & low pressure capability:
    • High pressure: 0–320 bar
    • Low pressure: 0–20 MPa
  • Automatic shutdown ensures accurate and consistent PCP filling
  • Durable performance: Long service life with minimal maintenance
  • Oil-free & water-free: No lubrication or cooling water required
  • User friendly: Compact, easy to use and carry
  • Quiet operation:Low sound and vibration levels
  • Integrated filtration:Built-in oil and water separator
  • Patented technology





  • Weight: 10kg
  • Dimensions: H: 300mm, W: 300mm, D: 200mm
  • Fill Line: 500mm with Foster QD fitting (QD adapter required for threaded probes)
  • Power: 240v mains or 12v DC car battery (cables included)
  • Maximum Pressure: 300BAR
  • Filling Time:
    • 0.3L cylinder: 6-7 minutes (200BAR to 300BAR)
    • 0.3L cylinder: 18-20 minutes (0BAR to 300BAR)
  • Cooling System: Air-cooled with water trap and manual bleed system

Specifications

BrandBSA
TypeAccessory
